But most parameters are optional as default values are provided. OpenJSCAD adheres to specific standards for passing parameters to functions. OpenJSCAD executes the script, and renders the 3D design for viewing. Training and help about JavaScript can be found online.Ĭreating a new design starts by writing simple scripts which call CSG functions, and other special functions, as provided by OpenJSCAD. In general, designs are written using the JavaScript language. You can share designs with other people by providing creating special URL which combines OpenJSCAD and Design. Sharing Designs via Direct Link for Local or Remote JSCAD, SCAD, STL and AMF When you start to edit directly using your browser, the default language is JSCAD. When you drag & drop files, the language or format is set according the file extension (.jscad, etc). Open standards file format to represent 3D objects using XML. STL files describe only the surface geometry of three-dimensional objectsĪdditive Manufacturing File Format (very experimental)ĭrawing Interchange File Format (export only)

#Openscad examples software#

OpenSCAD is a software for creating solid 3D CAD objects. JSCAD is a software for creating solid 3D CAD objects using your browser. Supported Language / File Formats Ĭurrently following languages and file-formats are supported:

#Openscad examples how to#

See also how to pass variables from the CLI to main().

-of stands for output format (jscad, stl (default), stla, stlb, amf, dxf).

% openjscad example001.jscad -of stlb -o test.stl % openjscad example001.jscad -of stlb # creates example001.stl (binary) % openjscad example001.jscad -of amf # creates example001.amf % openjscad example001.jscad -o example001.amf % openjscad frog.stl -o frog2.stl # does actually stl -> jscad -> stl (ascii) % openjscad example001.scad -o example001.stl % openjscad example001.scad -o example001.jscad Which creates ``logo.stl`` or ``test.stl``.Īdditional you can import OpenSCAD (.scad), STL ASCII or Binary (.stl) and AMF (.amf) files, and create. You can drag and drop any of the examples, as well as other designs or files. Note: Chrome and other browsers do not support drag and drop when offline. You can drag and drop a file or a folder to the browser. Once installing locally, OpenJSCAD can be accessed by opening `index.html` with your browser. NOTE: You might need configuration changes to allow access to the some of the contents (examples etc). This is the preferred installation if creating a website for online use. OpenJSCAD can be easily installed from GitHub as well. Now OpenJSCAD can be downloaded and installed by: We test OpenJSCAD using both Node.js version 6.x.x & 7.x.x. Note: A LTS version of Node.js > 6.0.0 is required. OpenJSCAD can be easily installed using Node Version Manager (NVM) Will start your webbrowser (Example script works on MacOs) To find the location of your index.html you might want to find out where your OpenJSCAD resides.

You can then use your browser like a locally installed application by opening 'index.html'. OpenJSCAD can be installed locally via GitHub or NPM. If you are having problems then please try another browser. Note: Each browser (Firefox, Chrome, IE, etc) supports slightly different functionality. Any changes to the files will be reloaded automatically. In order to use your favorite editor, make sure Auto Reload is selected. You can start editing by dragging a file or a folder to the area indicated.

edit online using the built-in editor, or.

OpenJSCAD presents a page which shows a 3D viewer, as well as an editor: OpenJSCAD can be used immediately by visiting the project website at openjscad.xyz OpenJSCAD User Guide Using OpenJSCAD via Web Browsers 6.4 Developing with Multiple JSCAD Files.5.1 Parameters via the Command Line Interface.1.4 Sharing Designs via Direct Link for Local or Remote JSCAD, SCAD, STL and AMF.
